Engines: High-Torque GX430T LBP



* Price may vary depending on location.

* Photo may vary from the actual unit.

* New High Tourque Mega Marine Variant






New High-Torque Engine, subok na matatag at ligtas para sa transportatsyon at turismo.


New High-Torque Engine, subok na matatag at ma-aasahan sa pangingisda.


Engines: High-Torque GX430T LBP

SRP: ₱ 37,900

Category: Fishery

Displacement (cc): 425 cc (25.9 cu-in)

Net Power: 12.4 kW (16.9 PS) / 4,000 rpm

Find a dealer for this product.
Type: 4-Stroke, OHV, single-cylinder, inclined 25º
Displacement (cc): 425 cc (25.9 cu-in)
Bore x stroke: 88.0 x 70.0 mm (3.5 x 2.76 in)
Net power (SAE J1349) * 1: 12.4 kW (16.9 PS) / 4,000 rpm
Maximum RPM 5,000
Maximum Torque (Measured at PTO): 37.6 N-m/ 2,400 rpm
Fuel consumption (at continuos rated power): *1 6.1 L
Compression Ratio: 8.5 : 1
Ignition system: CDI Type Magneto
Lubrication system: Forced splash
Oil capacity: 1.1 Liter (1.16 US qt, 0.97 lmp qt)
Starting System Recoil Starter
Starting system: Recoil starter
Air cleaner: Special air cleaner for boat (No air cleaner filter)
Reduction: 1:1.2 (20% Gear Reduction)
Dry weight: 33.2 kg
PTO diameter: 24.993 mm
Exhaust system: Stainless steel exhaust pipe



Data Specifications are subject to change at any time without prior notice.

* The power rating of the engine indicated in this document is the net power output tested on a pre production engine for the engine model and measured in accordance with SAE J1349 at 4,000 RPM (Engine Net Power) and at 4,000 RPM (Engine Max. Net Torque). Mass production engines may vary from this value. Actual power output for the engine to be mounted on the manufacture of the final machine will vary depending on many factors, including the operating speed of the engine in application, environmental conditions, maintenance and other variables.
